jector punch

Factory produce Precision ejector punch with elliptic shape

ms mold parts
A precision punching tool with an elliptical (oval) profile, designed for creating non-circular holes or features in materials. Made from hardened steel (e.g., HSS) and custom-engineered for specialized stamping, ejecting, or forming applications where standard round punches are unsuitable.
Delivery
FOB
minimum order
1 piece
Supply Ability
10000.0piece / Month
Country of Origin
ShenZhen GuangZhou
Quantity:
USD0.10 - USD9.00 / piece
Contact Now
add to cart

  • Our Elliptic Shape Punch represents a specialized category of precision tooling designed for unique manufacturing requirements. These custom-engineered punches feature precisely controlled elliptical and oval profiles, providing optimal solutions for applications where standard circular punches cannot achieve the desired results. As part of our comprehensive ejector punch lineup, these elliptic shape tools deliver exceptional performance in specialized stamping, punching, and ejection operations.

    Key Features

  • Precision Elliptic Geometry

    • Mathematically perfect elliptical profiles with controlled major/minor axis ratios

    • Custom oval configurations with specific dimensional requirements

    • Complex non-circular geometries for specialized applications

  • Advanced Material Technology

    • High-Speed Steel (HSS M2/M35) for superior edge retention

    • Powder Metallurgy Steel (ASP-23/30) for enhanced toughness in complex shapes

    • Tungsten Carbide inserts for extreme wear applications

    • Special surface coatings (TiN, TiCN) for reduced friction

  • Precision Manufacturing Excellence

    • CNC grinding technology ensuring profile accuracy within ±0.005mm

    • Specialized heat treatment for uniform hardness throughout complex shapes

    • Micro-grain structure optimization for maximum edge integrity

  • Technical Specifications

  • Materials: HSS, PM Steel, Tungsten Carbide

  • Hardness: HRC 62-65 (HSS), HRC 64-67 (PM Steel)

  • Standard Size Range: 2.0-25.0mm major axis

  • Profile Accuracy: ±0.005mm

  • Surface Treatments: TiN, TiCN, TiAlN coatings available

  • Temperature Resistance: Up to 550°C with specialized coatings

Product Description
Specification
Material
Carbide,ASP23,Vanadis,CPMRTXM4,SKD11,SKD61,HSS,A2,M2,D2,SUJ2,S45C,ect
Standard
Dayton,Lane,DIN,ISO,MISUMI,EDM,FIBRO,MOELLER,HASCO,ect
Size
Depend on your drawings or products standard
Place of origin
Dongguan, Guangdong, China
Heat treatment
Available
Surface Work
TiCN, TiN, Aitain, Ticrn, nitriding , Black oxygened, Black coating etc available
Tolerance
+ - 0.002mm
Polishness
Close to Ra0.2
Hardness
Depends on material(HRC60~94)
Delivery time
3-5 Working days, depends on the quantity the order. Express by DHL, UPS, FEDEX, TNT or Ocean Shipping etc.
Main Products
Guide elements, punch pin, die button, ejector pin and sleeve, oilless bush, etc.
