Guide Button for Punch DIN ISO 8978 Die bushes with starting hole

ms mold parts
A guide button for punch is a precision component that ensures accurate alignment and stable guidance of punches in stamping dies. It reduces deflection and wear, crucial for maintaining quality in high-volume production.
Delivery
FOB
minimum order
1 piece
Supply Ability
10000.0piece / Month
Country of Origin
ShenZhen GuangZhou
Quantity:
USD0.10 - USD9.00 / piece
Contact Now
add to cart

  • Product Overview
    Our Guide Button for Punch is an essential component designed to maintain precise alignment and stability in stamping and punching operations. Engineered to work seamlessly with Die bushes with starting hole, this critical tooling accessory ensures smooth operation and extended service life for your die sets. While we provide a comprehensive tungsten carbide ring size chart for material selection, our guide buttons are available in various materials to suit different application requirements.

    Key Features & Benefits:

  • Precision Alignment
    The Guide Button for Punch guarantees accurate punch guidance throughout the operation cycle, reducing deflection and maintaining perfect alignment with the Die bushes with starting hole.

  • Enhanced Durability
    Manufactured from high-grade tool steels or tungsten carbide, our guide buttons withstand high-impact forces and continuous operation, significantly extending your tooling system's service life.

  • Reduced Maintenance
    The precision-fit design minimizes wear on both the guide button and mating components, lowering maintenance frequency and costs while ensuring consistent performance.

  • Optimized Performance
    Working in harmony with Die bushes with starting hole, our guide buttons ensure smooth punch movement, reduce vibration, and improve overall stamping quality.

  • Technical Specifications:

  • Materials Available: Tool Steel, Tungsten Carbide

  • Hardness: HRC 60-65 (Tool Steel); HRA 90+ (Tungsten Carbide)

  • Surface Finish: Precision ground to Ra 0.4μm

  • Temperature Resistance: Up to 500°C (depending on material)

  • Compatibility: Standard and custom sizes available

Product Description
Specification
Material
Carbide,ASP23,Vanadis,CPMRTXM4,SKD11,SKD61,HSS,A2,M2,D2,SUJ2,S45C,ect
Standard
Dayton,Lane,DIN,ISO,MISUMI,EDM,FIBRO,MOELLER,HASCO,ect
Size
Depend on your drawings or products standard
Place of origin
Dongguan, Guangdong, China
Heat treatment
Available
Surface Work
TiCN, TiN, Aitain, Ticrn, nitriding , Black oxygened, Black coating etc available
Tolerance
+ - 0.002mm
Polishness
Close to Ra0.2
Hardness
Depends on material(HRC60~94)
Delivery time
3-5 Working days, depends on the quantity the order. Express by DHL, UPS, FEDEX, TNT or Ocean Shipping etc.
Main Products
Guide elements, punch pin, die button, ejector pin and sleeve, oilless bush, etc.
