HSS DIN 9861D punch

HSS DIN 9861D punch 5mm DIA punsch for stamping mold

ms mold parts
A high-speed steel punch compliant with DIN 9861D standards, featuring a precise 5mm diameter for accurate hole punching in stamping molds. Made of HSS material (HRC 62-65), it ensures wear resistance, durability, and consistent performance in high-precision stamping operations. Ideal for progressive dies and electronic or automotive component production.
Delivery
FOB
minimum order
1 piece
Supply Ability
10000.0piece / Month
Country of Origin
ShenZhen GuangZhou
Quantity:
USD0.10 - USD9.00 / piece
Contact Now
add to cart

  • Our HSS DIN 9861D Punch represents the pinnacle of precision and durability in industrial stamping tooling. This specialized product line combines high-speed steel DIN 9861D standard punches with exact 5mm diameter punch tools and comprehensive stamping mold precision components, delivering exceptional performance in demanding manufacturing environments. Engineered to meet rigorous German industrial standards, these tools ensure perfect compatibility, extended service life, and reliable operation across various stamping applications.

    Key Features

  • DIN 9861D Standard Compliance

    • Full conformity with DIN 9861D specifications

    • Certified high-speed steel material quality

    • Interchangeable with global standard tooling systems

  • Precision 5mm Diameter Design

    • Exact 5.0mm diameter with ±0.003mm tolerance

    • Optimized geometry for clean punching operations

    • Perfect for precision hole punching applications

  • Advanced HSS Material Performance

    • High-speed steel construction (HSS M2/M35)

    • Superior wear resistance and red hardness

    • Excellent toughness for high-impact applications

  • Technical Specifications

  • Standard: DIN 9861D

  • Material: High-Speed Steel (HSS M2/M35)

  • Diameter: 5.0mm (±0.003mm)

  • Hardness: HRC 62-65

  • Surface Finish: Ra 0.2μm maximum

  • Length Options: 40-120mm

  • Straightness: 0.005mm/100mm maximum

  • Temperature Resistance: Up to 550°C

Product Description
Specification
Material
Carbide,ASP23,Vanadis,CPMRTXM4,SKD11,SKD61,HSS,A2,M2,D2,SUJ2,S45C,ect
Standard
Dayton,Lane,DIN,ISO,MISUMI,EDM,FIBRO,MOELLER,HASCO,ect
Size
Depend on your drawings or products standard
Place of origin
Dongguan, Guangdong, China
Heat treatment
Available
Surface Work
TiCN, TiN, Aitain, Ticrn, nitriding , Black oxygened, Black coating etc available
Tolerance
+ - 0.002mm
Polishness
Close to Ra0.2
Hardness
Depends on material(HRC60~94)
Delivery time
3-5 Working days, depends on the quantity the order. Express by DHL, UPS, FEDEX, TNT or Ocean Shipping etc.
Main Products
Guide elements, punch pin, die button, ejector pin and sleeve, oilless bush, etc.
