hardened guide bush for stamping die sets

mold Guide bushings hardened guide bush for stamping die sets, hardened guide bush

ms mold parts
Tolerance: h6 grade available
Delivery
FOB
minimum order
1 piece
Supply Ability
10000.0piece / Month
Country of Origin
ShenZhen GuangZhou
Quantity:
USD0.10 - USD9.00 / piece
Contact Now
add to cart

  • Enhanced Durability

    • Hardened guide bush options with HRC 60+ surface hardness

    • Superior wear resistance for extended service life

    • Excellent dimensional stability under high loads

  • Precision Engineering

    • Precision grinding ensures tight tolerances

    • Optimal surface finish (Ra 0.8μm max) for smooth operation

    • Perfect concentricity for accurate guidance

  • Versatile Applications

    • Hardened guide bush specifically designed for stamping die sets

    • Comprehensive mold guide bushings for injection and compression molds

    • Available in standard and custom configurations

  • Technical Specifications

  • Materials: High-carbon chromium steel (SUJ2 equivalent)

  • Hardness: HRC 60-64 (hardened series)

  • Surface Finish: Ra 0.8μm max

  • Standard Sizes: 10-100mm diameters

  • Tolerance: h6 grade available

Product Description
Specification
Material
Carbide,ASP23,Vanadis,CPMRTXM4,SKD11,SKD61,HSS,A2,M2,D2,SUJ2,S45C,ect
Standard
Dayton,Lane,DIN,ISO,MISUMI,EDM,FIBRO,MOELLER,HASCO,ect
Size
Depend on your drawings or products standard
Place of origin
Dongguan, Guangdong, China
Heat treatment
Available
Surface Work
TiCN, TiN, Aitain, Ticrn, nitriding , Black oxygened, Black coating etc available
Tolerance
+ - 0.002mm
Polishness
Close to Ra0.2
Hardness
Depends on material(HRC60~94)
Delivery time
3-5 Working days, depends on the quantity the order. Express by DHL, UPS, FEDEX, TNT or Ocean Shipping etc.
Main Products
Guide elements, punch pin, die button, ejector pin and sleeve, oilless bush, etc.
