heat treatment punch pin

Mold punches with heat treatment Standard Punch pin Standard Punch

ms mold parts
A versatile, industrially standardized metal-forming tool with precise dimensions and heat-treated hardness (HRC 58-62). Used in stamping, piercing, or molding applications, it ensures consistent performance, durability, and interchangeability in dies and machinery
Delivery
FOB
minimum order
1 piece
Supply Ability
10000.0piece / Month
Country of Origin
ShenZhen GuangZhou
Quantity:
USD0.10 - USD9.00 / piece
Contact Now
add to cart

  • Our Standard Punch represents the foundation of reliable and precise punching operations across various industrial applications. This comprehensive product line includes specialized mold punches for precision tooling and heat-treated punch pins for enhanced durability, delivering consistent performance and extended service life in demanding manufacturing environments.

    Key Features

  • Precision Engineering

    • Tight dimensional tolerances maintained within ±0.01mm

    • Optimized geometries for specific application requirements

    • Superior surface finish for reduced friction and wear

  • Advanced Heat Treatment

    • Vacuum heat treatment for uniform hardness distribution

    • Customized tempering processes for optimal toughness

    • Consistent HRC 58-62 hardness across all components

  • Material Excellence

    • High-speed steel (HSS) for superior wear resistance

    • Tool steel variants for specific application needs

    • Full material traceability and certification

  • Technical Specifications

  • Materials: HSS (M2), Tool Steel (D2, A2)

  • Hardness: HRC 58-62 (standard range)

  • Diameter Range: 1.0-25.0mm

  • Length Options: 20-150mm

  • Surface Finish: Ra 0.4μm maximum

  • Straightness: 0.01mm/100mm maximum

Product Description
Specification
Material
Carbide,ASP23,Vanadis,CPMRTXM4,SKD11,SKD61,HSS,A2,M2,D2,SUJ2,S45C,ect
Standard
Dayton,Lane,DIN,ISO,MISUMI,EDM,FIBRO,MOELLER,HASCO,ect
Size
Depend on your drawings or products standard
Place of origin
Dongguan, Guangdong, China
Heat treatment
Available
Surface Work
TiCN, TiN, Aitain, Ticrn, nitriding , Black oxygened, Black coating etc available
Tolerance
+ - 0.002mm
Polishness
Close to Ra0.2
Hardness
Depends on material(HRC60~94)
Delivery time
3-5 Working days, depends on the quantity the order. Express by DHL, UPS, FEDEX, TNT or Ocean Shipping etc.
Main Products
Guide elements, punch pin, die button, ejector pin and sleeve, oilless bush, etc.
