punch pin mold

Precision special shape punch Customized hole punch for mold punch pin

ms mold parts
Specialized tools designed with non-standard geometries (e.g., polygonal, asymmetric) to create unique holes or features in materials. Made from hardened steel (e.g., HSS, carbide) with tight tolerances (±0.002mm), they enable custom punching solutions for complex mold, stamping, or precision manufacturing needs.
Delivery
FOB
minimum order
1 piece
Supply Ability
10000.0piece / Month
Country of Origin
ShenZhen GuangZhou
Quantity:
USD0.10 - USD9.00 / piece
Contact Now
add to cart

  • Our Special Geometry Punch Tools represent the cutting edge of custom tooling innovation, designed to meet the most complex and demanding manufacturing requirements. This comprehensive product line integrates specialized geometry punch tools, fully customized hole punch solutions, and precision punch pin mold components to deliver unparalleled performance in unique stamping and molding applications. Engineered for exacting specifications and challenging geometries, these tools enable manufacturers to achieve precision results that standard tooling cannot accomplish.

    Key Features

  • Advanced Geometry Capabilities

    • Complex profiles including polygonal, asymmetric, and hybrid shapes

    • Multi-level and stepped configurations for compound operations

    • Micro-tolerance maintenance within ±0.002mm

  • Custom Hole Punch Technology

    • Tailored hole shapes and sizes beyond standard circular patterns

    • Specialized edge geometries for specific material requirements

    • Optimized clearance angles for different material thicknesses

  • Precision Mold Integration

    • Perfect compatibility with various mold base systems

    • Custom shank configurations for specific press requirements

    • Enhanced alignment features for precise positioning

  • Technical Specifications

  • Materials: HSS M2/M35, Powder Metallurgy Steel, Tungsten Carbide

  • Hardness: HRC 62-67 (depending on material selection)

  • Profile Tolerance: ±0.002mm

  • Surface Finish: Ra 0.1-0.2μm

  • Size Range: 1.0-50.0mm (custom sizes available)

  • Temperature Resistance: Up to 600°C (with specialized materials)

Product Description
Specification
Material
Carbide,ASP23,Vanadis,CPMRTXM4,SKD11,SKD61,HSS,A2,M2,D2,SUJ2,S45C,ect
Standard
Dayton,Lane,DIN,ISO,MISUMI,EDM,FIBRO,MOELLER,HASCO,ect
Size
Depend on your drawings or products standard
Place of origin
Dongguan, Guangdong, China
Heat treatment
Available
Surface Work
TiCN, TiN, Aitain, Ticrn, nitriding , Black oxygened, Black coating etc available
Tolerance
+ - 0.002mm
Polishness
Close to Ra0.2
Hardness
Depends on material(HRC60~94)
Delivery time
3-5 Working days, depends on the quantity the order. Express by DHL, UPS, FEDEX, TNT or Ocean Shipping etc.
Main Products
Guide elements, punch pin, die button, ejector pin and sleeve, oilless bush, etc.
