Tungsten Carbide Punch Die Set

Professional Various Poincon Et Matrices Stepped Holder Punzones In Component Carbide Punch Press Die Set

ms mold parts
High-accuracy punching and stamping tooling components, comprising precisely matched punches (poinçons) and dies (matrices). Designed for micro-tolerance operations, they ensure clean cutting, extended durability, and consistent performance in metal forming industries.
Delivery
FOB
minimum order
1 piece
Supply Ability
10000.0piece / Month
Country of Origin
ShenZhen GuangZhou
Quantity:
USD0.10 - USD10.00 / piece
Contact Now
add to cart

  • Our Precision Poincon Et Matrices represent the highest standard in industrial stamping and punching tooling. As specialized components that include hardened stepped holder punzones and tungsten carbide punch die sets, these precision-engineered solutions deliver exceptional accuracy, durability, and performance for demanding metal forming applications.

    Key Features

  • Ultra-Precision Manufacturing

    • Micro-tolerance machining within ±0.002mm

    • Mirror surface finishes achieving Ra 0.1μm

    • Perfect dimensional stability under high-pressure operations

  • Enhanced Material Performance

    • Premium tool steel matrices with special heat treatment

    • Tungsten carbide punch options for extreme wear resistance

    • Stepped holder designs for optimal stress distribution

  • Optimized Tooling Design

    • Custom configurations for specific material thicknesses

    • Special clearances for different material types

    • Anti-vibration features for high-speed operations

  • Technical Specifications

  • Material Options:

    • High-Speed Steel (HSS)

    • Tungsten Carbide (YG/YF series)

    • Powder Metallurgy Steel

  • Hardness Range: HRC 58-65 (HSS), HRA 89-93 (Carbide)

  • Standard Sizes: 1-50mm punch diameters

  • Matrix Opening Tolerance: ±0.003mm

  • Surface Finish: Ra 0.1-0.4μm

Product Description
Specification
Material
Carbide,ASP23,Vanadis,CPMRTXM4,SKD11,SKD61,HSS,A2,M2,D2,SUJ2,S45C,ect
Standard
Dayton,Lane,DIN,ISO,MISUMI,EDM,FIBRO,MOELLER,HASCO,ect
Size
Depend on your drawings or products standard
Place of origin
Dongguan, Guangdong, China
Heat treatment
Available
Surface Work
TiCN, TiN, Aitain, Ticrn, nitriding , Black oxygened, Black coating etc available
Tolerance
+ - 0.002mm
Polishness
Close to Ra0.2
Hardness
Depends on material(HRC60~94)
Delivery time
3-5 Working days, depends on the quantity the order. Express by DHL, UPS, FEDEX, TNT or Ocean Shipping etc.
Main Products
Guide elements, punch pin, die button, ejector pin and sleeve, oilless bush, etc.
