punch and die set

Punch tool die locating pins for tool and die components

ms mold parts
Discover precision stamping die components including punch tool die systems, locating pins, and tool and die components. Ensure accurate alignment, durability, and efficient production. Request technical specs today.
Delivery
FOB
minimum order
1 piece
Supply Ability
10000.0piece / Month
Country of Origin
ShenZhen GuangZhou
Quantity:
USD0.10 - USD9.00 / piece
Contact Now
add to cart

  • Our Stamping Die Components represent the foundation of precision metal stamping operations, offering a comprehensive range of essential tooling elements. This complete product line includes precision punch tool die systems, reliable locating pins, and various critical tool and die components engineered to work seamlessly together. Designed for durability, accuracy, and optimal performance, these components ensure your stamping operations achieve maximum efficiency and productivity.

    Key Features

  • Precision Engineering Excellence

    • Micro-ground surfaces achieving Ra 0.2μm finish for smooth operation

    • Tight tolerance control within ±0.005mm for perfect fit

    • Optimized geometries for enhanced performance and longevity

  • Premium Material Selection

    • High-speed steel (HSS) for punch tool die components

    • Bearing steel (SUJ2) for locating pins and guide components

    • Tool steel variants for specific application requirements

  • Enhanced Durability

    • Heat treated to HRC 58-64 depending on application needs

    • Superior wear resistance for extended service life

    • Corrosion protection treatments available

  • Technical Specifications

  • Materials: HSS, SUJ2, Tool Steel Alloys

  • Hardness Range: HRC 58-64

  • Surface Finish: Ra 0.2-0.4μm

  • Standard Sizes: Customizable to specific requirements

  • Temperature Resistance: -30°C to 400°C

  • Compliance: ISO 9001, DIN standards

Product Description
Specification
Material
Carbide,ASP23,Vanadis,CPMRTXM4,SKD11,SKD61,HSS,A2,M2,D2,SUJ2,S45C,ect
Standard
Dayton,Lane,DIN,ISO,MISUMI,EDM,FIBRO,MOELLER,HASCO,ect
Size
Depend on your drawings or products standard
Place of origin
Dongguan, Guangdong, China
Heat treatment
Available
Surface Work
TiCN, TiN, Aitain, Ticrn, nitriding , Black oxygened, Black coating etc available
Tolerance
+ - 0.002mm
Polishness
Close to Ra0.2
Hardness
Depends on material(HRC60~94)
Delivery time
3-5 Working days, depends on the quantity the order. Express by DHL, UPS, FEDEX, TNT or Ocean Shipping etc.
Main Products
Guide elements, punch pin, die button, ejector pin and sleeve, oilless bush, etc.
