Standard punch regular pilots with black head Provide laser lettering service

ms mold parts
Standardized punch pilots featuring black oxide surface treatment (rust-proof, friction-reducing) and laser lettering service (permanent marking). Suitable for precision stamping dies to ensure accurate alignment, while supporting custom branding, model numbers, and text engraving to enhance tool traceability and professionalism.
Delivery
FOB
minimum order
1 piece
Supply Ability
10000.0piece / Month
Country of Origin
ShenZhen GuangZhou
Quantity:
USD0.10 - USD9.00 / piece
Contact Now
add to cart
  • Product Name:Mold Punch

  • Our Precision Punch Pilots represent the highest standard of accuracy and durability in industrial tooling systems. This comprehensive product line combines precision-engineered punch pilots with advanced black oxide coating technology and professional laser marking services, delivering exceptional performance and traceability in demanding manufacturing environments. Engineered for perfect alignment, corrosion resistance, and permanent identification, these solutions ensure reliable operation and extended service life across various industrial applications.

    Key Features

  • Precision Pilot Technology

    • Micro-ground pilot surfaces achieving Ra 0.4μm finish

    • Tight diameter tolerance control within ±0.003mm

    • Perfect concentricity for accurate material guidance

  • Black Oxide Coating Advantages

    • Superior corrosion resistance and durability

    • Reduced friction coefficient for smoother operation

    • Enhanced aesthetic appearance with matte black finish

    • Minimal dimensional change post-coating

  • Professional Laser Marking Service

    • Permanent alphanumeric identification and branding

    • High-contrast markings resistant to wear and chemicals

    • Custom logos, serial numbers, and technical specifications

    • Non-contact process preserving material integrity

  • Technical Specifications

  • Materials: High-Speed Steel, Tool Steel, Alloy Steel

  • Coating: Black Oxide (2-5μm)

  • Hardness: HRC 58-63

  • Surface Finish: Ra 0.4μm maximum

  • Pilot Diameters: 2.0-20.0mm

  • Length Options: 40-150mm

  • Marking Depth: 0.01-0.05mm

  • Marking Resolution: Up to 0.1mm character height

Product Description
Specification
Material
Carbide,ASP23,Vanadis,CPMRTXM4,SKD11,SKD61,HSS,A2,M2,D2,SUJ2,S45C,ect
Standard
Dayton,Lane,DIN,ISO,MISUMI,EDM,FIBRO,MOELLER,HASCO,ect
Size
Depend on your drawings or products standard
Place of origin
Dongguan, Guangdong, China
Heat treatment
Available
Surface Work
TiCN, TiN, Aitain, Ticrn, nitriding , Black oxygened, Black coating etc available
Tolerance
+ - 0.002mm
Polishness
Close to Ra0.2
Hardness
Depends on material(HRC60~94)
Delivery time
3-5 Working days, depends on the quantity the order. Express by DHL, UPS, FEDEX, TNT or Ocean Shipping etc.
Main Products
Guide elements, punch pin, die button, ejector pin and sleeve, oilless bush, etc.
