precision press die components

Tablet Press Tool DIN Round Head Needle Metal Ejector Punch Press die components

ms mold parts
A hardened steel tool with a spherical head design, used in press dies or molds to eject finished parts. The round head distributes impact forces evenly, reduces stress concentration, and ensures reliable performance in high-cycle stamping or molding operations.
Delivery
FOB
minimum order
1 piece
Supply Ability
10000.0piece / Month
Country of Origin
ShenZhen GuangZhou
Quantity:
USD1.00 - USD25.00 / piece
Contact Now
add to cart

  • Our Round Head Ejector Punch and Precision Press Die Components represent the highest standard of quality and reliability in industrial press and molding operations. These meticulously engineered components are designed to deliver exceptional performance in demanding manufacturing environments, ensuring smooth ejection, precise operation, and extended service life. The innovative round head design provides superior strength and reliability while maintaining perfect compatibility with standard press die systems.

    Key Features

  • Optimized Round Head Design

    • Spherical head geometry for even stress distribution

    • Enhanced impact resistance and load-bearing capacity

    • Reduced stress concentration at critical points

  • Precision Manufacturing Excellence

    • CNC machining ensuring tolerances within ±0.005mm

    • Micro-ground surfaces achieving Ra 0.4μm finish

    • Perfect concentricity between head and shank

  • Premium Material Construction

    • High-grade tool steel with superior toughness

    • Vacuum heat treatment for uniform HRC 58-62 hardness

    • Excellent wear and fatigue resistance

  • Technical Specifications

  • Material: High-Quality Tool Steel

  • Hardness: HRC 58-62

  • Surface Finish: Ra 0.4μm maximum

  • Head Diameter Range: 8-50mm

  • Shank Diameters: 6-40mm

  • Length Options: 40-200mm

  • Temperature Resistance: Up to 400°C

Product Description
Specification
Material
Carbide,ASP23,Vanadis,CPMRTXM4,SKD11,SKD61,HSS,A2,M2,D2,SUJ2,S45C,ect
Standard
Dayton,Lane,DIN,ISO,MISUMI,EDM,FIBRO,MOELLER,HASCO,ect
Size
Depend on your drawings or products standard
Place of origin
Dongguan, Guangdong, China
Heat treatment
Available
Surface Work
TiCN, TiN, Aitain, Ticrn, nitriding , Black oxygened, Black coating etc available
Tolerance
+ - 0.002mm
Polishness
Close to Ra0.2
Hardness
Depends on material(HRC60~94)
Delivery time
3-5 Working days, depends on the quantity the order. Express by DHL, UPS, FEDEX, TNT or Ocean Shipping etc.
Main Products
Guide elements, punch pin, die button, ejector pin and sleeve, oilless bush, etc.
