Key Features:

• DLC Coating Technology: The DLC coating offers extreme hardness (2,000-4,000 HV), low friction coefficient (<0.1), and anti-adhesion properties, significantly extending pin life.
• Meusburger Standard Compliance: Fully compatible with Meusburger standard systems, ensuring easy replacement and interoperability.
• Blade Design: The blade-style geometry provides efficient ejection for thin-walled parts, undercuts, and complex geometries.
• Premium Material: Made from high-grade tool steel (e.g., 1.2344) with heat treatment (48-52 HRC) for core toughness.
• Precision Manufacturing: Tight tolerances (±0.01mm) and polished surfaces ensure smooth operation and consistent performance.

Applications:

• Injection moulding of automotive components (e.g., interior trims, light guides)
• Electronics and consumer goods housing with cosmetic surface requirements
• Medical device moulding where cleanliness and minimal lubrication are critical
• High-volume production with abrasive materials (e.g., glass-filled polymers)
• Meusburger-compatible mold systems requiring reliable ejection solutions

Product Description

Specification

Material	Carbide,ASP23,Vanadis,CPMRTXM4,SKD11,SKD61,HSS,A2,M2,D2,SUJ2,S45C,ect
Standard	Dayton,Lane,DIN,ISO,MISUMI,EDM,FIBRO,MOELLER,HASCO,ect
Size	Depend on your drawings or products standard
Place of origin	Dongguan, Guangdong, China
Heat treatment	Available
Surface Work	TiCN, TiN, Aitain, Ticrn, nitriding , Black oxygened, Black coating etc available
Tolerance	+ - 0.002mm
Polishness	Close to Ra0.2
Hardness	Depends on material(HRC60~94)
Delivery time	3-5 Working days, depends on the quantity the order. Express by DHL, UPS, FEDEX, TNT or Ocean Shipping etc.
Main Products	Guide elements, punch pin, die button, ejector pin and sleeve, oilless bush, etc.
